The red and black wire from there connected to the NO side of the relay I found two pins that when shorted turned the TV on so I soldered two wires to those pins: The cable says P4 but it actually goes in the P5 spot on the expansion I/O board Most of the cables come labelled and say what area they connect to on the boards.
This is not connected to anything and appears to be for future use I built my own cable for the two player start buttons since mine was missingīasically I had a 6 prong connector that would plug into it then I divided the cables up based on the wiring diagram in the service manual Maybe this cable will work at replacing the need for the two cables above but I did not feel like waiting and I already had them lying around the house (Keep scrolling for more information about the audio connectors)įor the first female connector I bought this 3.5mm to 3.5mm cable (which plugs into the I/O PCB)įor the second female connector I had these items (Which connect together then connect to the Sub Amp PCB on the far right) On the very right side there is a coax cable that plugs into location B.
Take note of the red line on the cable to know what way to connect it This board plugs into the I/O PCB with the ribbon cable. Hard to see in the pic but on the far right a 3.5mm cable plugs in there from location BĪlso near the bottom of the board is where the serial cable plugs in to location E The game is onsite now so I cannot confirm but I know it is not P7 **Correction: I think the correct location is P2 actually (the one next to the USB connector) Notice USB cable near the bottom and power cable for location DĪt location P7 on the board that goes to location C USB Ports (USB Key, Guitars, and Watchdog PCB plug in here. Connects to Watchdog PCB (Coming Soon: How to make your own cable. Audio Splitter (scroll down for more info)Ĭ.
